Style

Freightliner, Kenworth, Peterbilt, Western Star

Size

Double 4" x 6"

Sold

Individually

Compliance

DOT/SAE | FMVSS-108 | CMVSS-108

Bulb Type

LED Projector

Function 1

Combination High & Low Beam

Function 2

Marker LEDs & Glow Position Halo Rings

LED Power

Low: 17.3 Watts | High: 19.2 Watts

Raw Lumens

Low: 1400 Lumens | High: 2100 Lumens

Effective Lumens

Low: 830 Lumens | High: 1225 Lumens

Operating Voltage

9-30 Volts (DRL Compatible)

Current Draw @ 12.8 Volts

Low: 1.25 Amps | High: 1.50 Amps

Function 2 Amperage

0.44 Amps @ 12 Volts

DRL Amperage (Watts/Amps)

0.16 Amps

Diodes

Low: 3 Diodes | High: 7 Diodes

Interior Color

Chrome

Lens Color

Clear

Lens Material

Polycarbonate

Housing Material

Polypropylene

Waterproof Rating

IP66 Rating

What's Included

Housing Bucket & Hardware Included

Package Dimensions

18.8"L x 9.5"W x 9.8"H

Package Weight

9.6 lbs

Inner Box QTY

1 PC

Outer Box Qty

6 PCS

Warranty

3 Year Warranty
